1968 Ign switch question
#1
1968 Ign switch question
Howdy all new here just bought a 68 442. Having some electrical starting problems and I need to get to the back side of the ign switch. the car is an AC car also and I wondered if any one could get me started in the right direction on dash removel or just to get to the back side of the switch with out breaking the dash? Thanks Doug
#2
Disco battery
Insert key
turn to ACC
insert paper clip or similar in hole next to key
turn MORE ccw past ACC
key/cylinder will pop out
Using special tool, unscrew switch bezel
twist switch back n forth to assist.
http://www.ebay.com/itm/68-Olds-cutl...0b3453&vxp=mtr
What, no special tool on hand?
Use your FINGERS on the plastic ring then - normal tools will mar the ring.
Fabricate a special tool that will exactly fit into two opposing slots in the ring? A tab would do. Sheetmetal rectangle.
Urge the ring CCW whilst twisting the switch body slightly back n forth backside.
This usually works.
Unscrew the plastic ring
bring the switch down where you can work on it.
uhg AC- may have to remove quite a bit of ducting
the fabric duct will fall apart. Don't touch if it possible./
Using paperclips per chassis service manual procedure to hold the 3 retainer fingers in the released position, pry the switch off the connector. Or vice versa.
Voila.
Insert key
turn to ACC
insert paper clip or similar in hole next to key
turn MORE ccw past ACC
key/cylinder will pop out
Using special tool, unscrew switch bezel
twist switch back n forth to assist.
http://www.ebay.com/itm/68-Olds-cutl...0b3453&vxp=mtr
What, no special tool on hand?
Use your FINGERS on the plastic ring then - normal tools will mar the ring.
Fabricate a special tool that will exactly fit into two opposing slots in the ring? A tab would do. Sheetmetal rectangle.
Urge the ring CCW whilst twisting the switch body slightly back n forth backside.
This usually works.
Unscrew the plastic ring
bring the switch down where you can work on it.
uhg AC- may have to remove quite a bit of ducting
the fabric duct will fall apart. Don't touch if it possible./
Using paperclips per chassis service manual procedure to hold the 3 retainer fingers in the released position, pry the switch off the connector. Or vice versa.
Voila.
Last edited by Octania; March 19th, 2015 at 09:56 AM.
#3
Welcome to the site. Maybe we can help without the removal of the switch if you give us an accurate and complete description of your electrical problem. Post a proper intro with a picture of your car in the newbie section when you get a chance.
#4
Well I got the switch out. Had no signal power to starter from switch wanted to test. I just didn't know how the dash came apart. The car has some ugly wiring under the dash. I need to find a wiring dia. to clean some of it up. any suggestions? I will post pics later. Thanks Doug
#5
Here is a diagram for a Chevelle, it's close. Check your neutral safety switch that's where the purple wire to your starter comes from.
https://s3.amazonaws.com/ClubExpress...6GTZEEiPkXU%3D
https://s3.amazonaws.com/ClubExpress...6GTZEEiPkXU%3D
#6
Welcome. If you are going to do any work on this car at all, get these manuals. Pay the money and buy paper originals on ebay. The digital versions are all scans of a paper original and resolution will be lost, especially on the small print in wiring diagrams. You can find them for around $15 each if you look.
#8
Is it a factory manual trans car, or converted? Manual trans cars do not use a neutral safety switch, they use a clutch safety switch on the clutch pedal and a separate backup light switch mounted on the trans and actuated directly from the reverse gear arm on the trans. For that matter, I don't know that 68s used the clutch safety switch, anyway.
#10
two of the bolts that hold the side plate on the transmission.
There should be a piece of linkage connecting the switch
to the reverse shift lever on the transmission.
Those green wires should be connected to the reverse light switch.
Last edited by 67442nut; March 19th, 2015 at 01:01 PM.
#13
http://www.ebay.com/itm/201036335180...%3AMEBIDX%3AIT
You can't just put it in Park then
The purple wires is a good start.
Can you ck for voltage at the underdash purple wires when in START mode?
removing the ign sw was not necessary then eh?
next ck the purple wires under the hood on the way to the starter.
then at the starter
then the starter grounding
then the starter / solenoid itself
You can't just put it in Park then
The purple wires is a good start.
Can you ck for voltage at the underdash purple wires when in START mode?
removing the ign sw was not necessary then eh?
next ck the purple wires under the hood on the way to the starter.
then at the starter
then the starter grounding
then the starter / solenoid itself
Last edited by Octania; March 19th, 2015 at 03:01 PM.
#14
Well, go back and re-read post #8, above. Then look for one of these on the transmission itself.
#15
#17
#19
Nice pic of the switch. Mine does not have one. Where do the wires go to? Mine are under the dash by the steering column . I am wondering if it was converted at some point due to the wires there. I ordered the books so I am hoping to figure the wiring out. Just wanted to say thanks guys for all the help so far.
#20
69 had the reverse lock out linkage, I don't know if they had the switch as well
On a 68, factory four (& three) speed floor shift, the underdash harness connector which normally plugs into the steering column reverse and neutral safety switch has a jumper in it to bypass the neutral safety (edit, this is only partially correct, see my next post). If I remember correctly it's a U-shaped clip. The reverse light harness plugs into the other side (or adjacent plug, I think there may be two separate ones) of the plug. Unfortunately I'm going from memory and my car is stored five miles away and I won't see it for at least another two weeks. I know I've seen the jumper detailed somewhere but can't find it now. (I thought it was in the Assembly Manual's Section 7 but I can't find it).
On a 68, factory four (& three) speed floor shift, the underdash harness connector which normally plugs into the steering column reverse and neutral safety switch has a jumper in it to bypass the neutral safety (edit, this is only partially correct, see my next post). If I remember correctly it's a U-shaped clip. The reverse light harness plugs into the other side (or adjacent plug, I think there may be two separate ones) of the plug. Unfortunately I'm going from memory and my car is stored five miles away and I won't see it for at least another two weeks. I know I've seen the jumper detailed somewhere but can't find it now. (I thought it was in the Assembly Manual's Section 7 but I can't find it).
Last edited by allyolds68; March 22nd, 2015 at 06:17 AM.
#21
So I found the jumper wire (lower left) but it's only with 35U21 (Rallye Pac). I don't remember why this is as it would seem either Rallye Pac or non-Rallye Pac SMT cars would require it. All I can figure out is for some reason non Rallye Pac SMT dash wiring harnesses would have the neutral start internally jumped.
edit: I'll bet they did it so they only had to make one Rallye Pac dash harness. A non Rallye Pac SMT car would be internally jumped and have the single reverse light connector for the trans switch harness. As my car was definitely an original SMT, it either had the dash harness changed/modified at some point or was originally Rallye Pac equipped because it had the jumper installed. When I got the car the gauge wires were arranged for an idiot light gauge pod but that could have been easily changed.
edit: I'll bet they did it so they only had to make one Rallye Pac dash harness. A non Rallye Pac SMT car would be internally jumped and have the single reverse light connector for the trans switch harness. As my car was definitely an original SMT, it either had the dash harness changed/modified at some point or was originally Rallye Pac equipped because it had the jumper installed. When I got the car the gauge wires were arranged for an idiot light gauge pod but that could have been easily changed.
Last edited by allyolds68; March 22nd, 2015 at 06:08 AM.
#22
Nice pic of the switch. Mine does not have one. Where do the wires go to? Mine are under the dash by the steering column . I am wondering if it was converted at some point due to the wires there. I ordered the books so I am hoping to figure the wiring out. Just wanted to say thanks guys for all the help so far.
I've got the 68 Wiring diagram scanned in high rez. If you'd like it give me you're email address and I'll send it to you in jpg and pdf. If you're old like me you can't read the diagram in the Service Manual without a magnifying glass. The electronic versions of the Service Manual that are available typically do not have enough resolution to read the wiring diagram.
Last edited by allyolds68; March 22nd, 2015 at 06:19 AM.
#23
#24
Azozbirns@msn.com in my email and yes would love a copy. thanks again guys huge help!
