Can a 1969 400 cid block be bored to be a 455?

I have an engine block from a 1969 442. It is currently 400 cubic inches with a 3.870 inch bore and a 4.250 inch stroke. Can it be bored out to 4.125 inches so that the displacement will be 455 cubic inches. It would then be the same bore, stroke, and displacement of the 1970 442 engine (which I think used the same block) and I would be able to use the crankshaft that I already have. Just wondering if this is possible on the block I have without hitting coolant lines or running into other problems.

Thanks
__________________
1969 red 442 convertible w/ black stripes
1969 blue 442 convertible w/ white stripes
red&blue442 is offline   Reply With Quote
Old January 12th, 2011, 05:51 PM   #2
Registered User

rptw32's Avatar

Join Date: Aug 2009
Location: S.E. Michigan
Posts: 96
Quote:
Originally Posted by red&blue442 View Post
I have an engine block from a 1969 442. It is currently 400 cubic inches with a 3.870 inch bore and a 4.250 inch stroke. Can it be bored out to 4.125 inches so that the displacement will be 455 cubic inches. It would then be the same bore, stroke, and displacement of the 1970 442 engine (which I think used the same block) and I would be able to use the crankshaft that I already have. Just wondering if this is possible on the block I have without hitting coolant lines or running into other problems.

Thanks

personally I wouldn't waste time or money trying - just find a 455 or 425 block and you're already there - Crank / rods from G block 400 can be used in either to get 455 cid. - the walls will be too thin after that much of overbore on the G block .
__________________
Rob Thomas
69 442 11.43 / 116
01 Aurora
rptw32 is offline   Reply With Quote
Old January 12th, 2011, 05:55 PM   #3
Registered User

red&blue442's Avatar

Join Date: Mar 2010
Location: Plano, Texas
Posts: 23
Isn't it the same block used on the 69 h/o and 70 442? Were the walls too thin on those engines? Or is it a different block? Just wondering because I can have the block bored and machined almost free
__________________
1969 red 442 convertible w/ black stripes
1969 blue 442 convertible w/ white stripes
red&blue442 is offline   Reply With Quote
Old January 12th, 2011, 06:08 PM   #4
Registered User

67442nut's Avatar

Join Date: Nov 2007
Location: Charleston, West Virginia
Posts: 586
Quote:
Originally Posted by red&blue442 View Post
I have an engine block from a 1969 442. It is currently 400 cubic inches with a 3.870 inch bore and a 4.250 inch stroke. Can it be bored out to 4.125 inches so that the displacement will be 455 cubic inches. It would then be the same bore, stroke, and displacement of the 1970 442 engine (which I think used the same block) and I would be able to use the crankshaft that I already have. Just wondering if this is possible on the block I have without hitting coolant lines or running into other problems.

Thanks
.255" overbore removes over 1/8" of cylinder wall thickness.
I don't know how thick the cylinder walls are, but, I'm sure that doesn't leave much.
You could probably bore it out to nothing and not get 55 cubic inches.
I think the 455 crank has a longer stroke than the 400.
The guys on the ROP site can give you exact numbers and good advice.
__________________
Ed Skaff

Last edited by 67442nut; January 12th, 2011 at 06:11 PM.
67442nut is offline   Reply With Quote
Old January 12th, 2011, 06:21 PM   #5
Registered User

allyolds68's Avatar

Join Date: Jul 2008
Location: Seneca Falls, NY
Posts: 2,518
Quote:
Originally Posted by red&blue442 View Post
Isn't it the same block used on the 69 h/o and 70 442?
While they are designed the same a 400 G and 455 F are not the same block. A 400 G block will not support that overbore, the cylinder walls aren't thick enough (not without sonic testing anyway). The stroke of a 400G & 455F are the same.

Like others said, buy a 455 block. You can usually get one for $100. All your other internals and heads will switch over.

Last edited by allyolds68; January 12th, 2011 at 06:25 PM.
allyolds68 is offline   Reply With Quote
Old January 12th, 2011, 09:01 PM   #6
Just the facts...

BILL DEMMER's Avatar

Join Date: May 2008
Location: THE GREAT WIDE-OPEN
Posts: 1,146
i have always heard that the sand castings around the cylinders were the same between the 400 and 455, and that the G block would support that overbore as long as there wasn't a major core shift issue.


bill
__________________
'67 CUTLASS 4-DR. W/425 & S.P. THM400 (NAMED "ERNIE")
'83 H/O #1339(STILL IN PIECES)
'85 PONTIAC FIERO SE V-6 4-SPD. BOUGHT NEW
'92 CHEBBY ASTRO
'97 GEO METRO LSi 41.42 MPG
BILL DEMMER is offline   Reply With Quote
Old January 12th, 2011, 10:31 PM   #7
Registered User

red&blue442's Avatar

Join Date: Mar 2010
Location: Plano, Texas
Posts: 23
Thanks for all the help. I know for a fact the 455 crank has the same stroke (4.250 in) as the 400 because I looked it up in a restoration manual, but what I'm worried about is the bigger bore to get the displacement. I am going to have it sonic tested anyways when it goes to the machinist, so hopefully I can bore it out that big but if I can't I'll just get as much power out of the 400 as possible. Looking at the block, it has over half an inch between cylinders, but I don't know where the coolant lines are or how big they are, and I also don't know much about how much room in between cylinders is mandatory. So the sonic testing should help whenever I get it done.

Thanks again for all the help
__________________
1969 red 442 convertible w/ black stripes
1969 blue 442 convertible w/ white stripes
red&blue442 is offline   Reply With Quote
Old January 13th, 2011, 05:33 AM   #8
Registered User

Join Date: Oct 2009
Location: Erie,PA
Posts: 3,816
You can't bore it that big.I would do +.030 The only way you would get the bore size of the 455 out of that block,is if you gutted it,and put 8 sleeves in it.
__________________
Brian Trick
thetrickfamily@yahoo.com
814-440-3553
70 W30's
71 W30
70 W31
72 Cutlass Supreme 507"
507OLDS is offline   Reply With Quote
Old January 13th, 2011, 05:44 AM   #9
Registered User

Join Date: Aug 2007
Posts: 1,951
Even if you could do it, at .030 a cut, that is 10 bores. The cost alone makes it not practical. As stated, blocks are $100, the machine work to bore that big would cost you much more than that. Plus the cost of the sonic test which you would not need on the 455.
captjim is offline   Reply With Quote
Old January 13th, 2011, 06:14 AM   #10
Registered User

allyolds68's Avatar

Join Date: Jul 2008
Location: Seneca Falls, NY
Posts: 2,518
Here's about every opinion on what you should and shouldn't do with your 400G block

http://www.realoldspower.com/phpBB2/...+bored+casting

Mine's sitting next to my furnace....
allyolds68 is offline   Reply With Quote
Old January 13th, 2011, 04:10 PM   #11
Old(s) Fart

joe_padavano's Avatar

Join Date: Mar 2007
Location: Northern VA
Posts: 16,297
Quote:
Originally Posted by BILL DEMMER View Post
i have always heard that the sand castings around the cylinders were the same between the 400 and 455, and that the G block would support that overbore as long as there wasn't a major core shift issue.


bill
Back in the days of the old Chubecto list server, Chris Witt claimed to have seen a cutaway G-block that had outrageously thick cylinder walls. Obviously sonic testing is needed, but as others have pointed out, why spend the money when 455 blocks are inexpensive.

Now, having said that, I'd like to figure out a way to do it just so I have the correct G-block casting in my 69 442. In that case, it is not a cost-based issue.
__________________
Joe Padavano

62 F-85 Deluxe wagon (the NV desert car)
62 F-85 Deluxe wagon (the San Jose car)
64 Vista Cruiser
64 Jetstar 88 Conv
66 442 L-69 Conv
68 W-30
69 H/O
69 442
70 W-30
72 442
84 Custom Cruiser
86 Caprice wagon (w/307 Olds)
joe_padavano is offline   Reply With Quote
Old January 13th, 2011, 04:11 PM   #12
Old(s) Fart

joe_padavano's Avatar

Join Date: Mar 2007
Location: Northern VA
Posts: 16,297
Quote:
Originally Posted by red&blue442 View Post
Thanks for all the help. I know for a fact the 455 crank has the same stroke (4.250 in) as the 400 because I looked it up in a restoration manual,
They use the same crank - same part number.
__________________
Joe Padavano

62 F-85 Deluxe wagon (the NV desert car)
62 F-85 Deluxe wagon (the San Jose car)
64 Vista Cruiser
64 Jetstar 88 Conv
66 442 L-69 Conv
68 W-30
69 H/O
69 442
70 W-30
72 442
84 Custom Cruiser
86 Caprice wagon (w/307 Olds)
joe_padavano is offline   Reply With Quote
Old January 13th, 2011, 05:19 PM   #13
Registered User

allyolds68's Avatar

Join Date: Jul 2008
Location: Seneca Falls, NY
Posts: 2,518
Quote:
Originally Posted by joe_padavano View Post
Back in the days of the old Chubecto list server, Chris Witt claimed to have seen a cutaway G-block that had outrageously thick cylinder walls.
I thought I remembered that Chris was talking about a 400E block

Last edited by allyolds68; January 13th, 2011 at 07:02 PM.
allyolds68 is offline   Reply With Quote
Old January 13th, 2011, 05:41 PM   #14
Registered User

Join Date: Oct 2009
Location: Erie,PA
Posts: 3,816
Well Joe,you could put 8 sleeves in it.
I know of a certain someone that uses 425 blocks,and sleeves them down,to make 67 400's for a stocker,making real think walls.
__________________
Brian Trick
thetrickfamily@yahoo.com
814-440-3553
70 W30's
71 W30
70 W31
72 Cutlass Supreme 507"
507OLDS is offline   Reply With Quote
Old January 13th, 2011, 06:45 PM   #15
"me somebody" site member

aliensatemybuick's Avatar

Join Date: Jul 2007
Posts: 1,394
I (still) say the best way to keep an externally correct looking (i.e. G) block in a '68 / '69 car while about matching the performance of the earlier cars would be to use the rods and crank from a 400/425 and a high-comp 330 piston (only would need a 0.068 overbore). CI would work out to about 388.

It'd sure be differ.
aliensatemybuick is offline   Reply With Quote
Old January 14th, 2011, 07:14 AM   #16
Old(s) Fart

joe_padavano's Avatar

Join Date: Mar 2007
Location: Northern VA
Posts: 16,297
Quote:
Originally Posted by allyolds68 View Post
I thought I remembered that Chris was talking about a 400E block
Well, that post was in the early 1990s. Memory is a funny thing. I guess we could ask him.
__________________
Joe Padavano

62 F-85 Deluxe wagon (the NV desert car)
62 F-85 Deluxe wagon (the San Jose car)
64 Vista Cruiser
64 Jetstar 88 Conv
66 442 L-69 Conv
68 W-30
69 H/O
69 442
70 W-30
72 442
84 Custom Cruiser
86 Caprice wagon (w/307 Olds)
joe_padavano is offline   Reply With Quote
Old January 14th, 2011, 07:15 AM   #17
Old(s) Fart

joe_padavano's Avatar

Join Date: Mar 2007
Location: Northern VA
Posts: 16,297
Quote:
Originally Posted by 507OLDS View Post
Well Joe,you could put 8 sleeves in it.
Yeah, the way they do to the new Hemi blocks. I'm sure THAT'S cheap...
__________________
Joe Padavano

62 F-85 Deluxe wagon (the NV desert car)
62 F-85 Deluxe wagon (the San Jose car)
64 Vista Cruiser
64 Jetstar 88 Conv
66 442 L-69 Conv
68 W-30
69 H/O
69 442
70 W-30
72 442
84 Custom Cruiser
86 Caprice wagon (w/307 Olds)
joe_padavano is offline   Reply With Quote
Old January 14th, 2011, 08:47 AM   #18
Registered User

Join Date: Oct 2009
Location: Erie,PA
Posts: 3,816
Then you could have a siamesed 400.
__________________
Brian Trick
thetrickfamily@yahoo.com
814-440-3553
70 W30's
71 W30
70 W31
72 Cutlass Supreme 507"
507OLDS is offline   Reply With Quote
Old January 14th, 2011, 11:04 AM   #19
Registered User

allyolds68's Avatar

Join Date: Jul 2008
Location: Seneca Falls, NY
Posts: 2,518
Quote:
Originally Posted by joe_padavano View Post
Well, that post was in the early 1990s. Memory is a funny thing. I guess we could ask him.
This is the quote from the FAQ on 442.com that I remembered from way back. It might not be the same thing you're refering to:
Quote:
Originally Posted by Chris_Witt
Ran my question about the 425 piston into the 400 'E' block by 'the rocket scientist', Chris Witt, and he related seeing a cutaway 400 engine at MSU. He recalled being amazed at the thickness of the cylinder--he measured 3/8". Sounds like going .063 won't pose any problem there. Apparently JM also says it's an OK deal.
allyolds68 is offline   Reply With Quote
Old January 14th, 2011, 11:42 AM   #20
Old(s) Fart

joe_padavano's Avatar

Join Date: Mar 2007
Location: Northern VA
Posts: 16,297
Quote:
Originally Posted by allyolds68 View Post
This is the quote from the FAQ on 442.com that I remembered from way back. It might not be the same thing you're refering to:
Well, memory is the second thing to go, and I can't remember the first...
__________________
Joe Padavano

62 F-85 Deluxe wagon (the NV desert car)
62 F-85 Deluxe wagon (the San Jose car)
64 Vista Cruiser
64 Jetstar 88 Conv
66 442 L-69 Conv
68 W-30
69 H/O
69 442
70 W-30
72 442
84 Custom Cruiser
86 Caprice wagon (w/307 Olds)
joe_padavano is offline   Reply With Quote
Old January 14th, 2011, 11:48 AM   #21
Old(s) Fart

joe_padavano's Avatar

Join Date: Mar 2007
Location: Northern VA
Posts: 16,297
Quote:
Originally Posted by 507OLDS View Post
Then you could have a siamesed 400.
Yeah, I mean so long as we're having wet dreams, why not use liners that take the bore out to 4.351.

Gotta say that I was in awe when I read about the shop that does that to the Hemi blocks.
__________________
Joe Padavano

62 F-85 Deluxe wagon (the NV desert car)
62 F-85 Deluxe wagon (the San Jose car)
64 Vista Cruiser
64 Jetstar 88 Conv
66 442 L-69 Conv
68 W-30
69 H/O
69 442
70 W-30
72 442
84 Custom Cruiser
86 Caprice wagon (w/307 Olds)
joe_padavano is offline   Reply With Quote
Old January 14th, 2011, 07:55 PM   #22
Registered User

ralsy's Avatar

Join Date: Jul 2010
Location: Sunshine Coast
Posts: 315
I'm just reading an article from Bill Trovato on B/B olds engines and he quotes Oldsmobile big blocks have many shared features and dimensions. The bore spacing between the cylinders is the same as all Olds engines at 4.625. The main housing bores are all set at 3.189. Which would make you think that the cylinder walls on a smaller bore big block would have the meat in them to overbore to same dimensions than the bigger bore engines? The water jacket holes are I think in the same position on the 400 and 455 blocks.
Reading further he does actually say that you should check inside the water jacket from the deck and the freeze plug area as some blocks have thicker walls. Some blocks have more rust in this area and therefore have thinner walls. He recommends sonic testing.
In that Realoldspower forum they never really proved that the G block 400 ci could or couldnít be over bored to a 455ci spec. I was waiting for someone to come back with a sonic tested 400ci B/B and give us the dimensions. I canít believe that nobody on this forum has had a 400ci G block sonic tested and kept the figures.
ralsy is offline   Reply With Quote
Old January 14th, 2011, 08:57 PM   #23
Registered User

Join Date: Oct 2009
Location: Erie,PA
Posts: 3,816
They are doing the same sleeving with the new LS blocks as well.They gut them,and put 8 sleeves in.I was looking at some blocks with Bill Trovato,and came up with a concoction of using a diesel block,putting 8 sleeves in it,with deck spacers,and 4.350" siamese bores.Using that with my billet 4.700" stroke crank would put me in the 550+ cube range.It "could" be done,but you do NOT want to bore the block all the way down,or you will end up with a windowed-main block,just like the 403's. As long as you determine how low the piston travels,the is no need to go further.If Oldsmobile would have done this to the 403 blocks,the world would be a much different place today.
__________________
Brian Trick
thetrickfamily@yahoo.com
814-440-3553
70 W30's
71 W30
70 W31
72 Cutlass Supreme 507"
507OLDS is offline   Reply With Quote
Old January 15th, 2011, 04:35 PM   #24
Registered User

red&blue442's Avatar

Join Date: Mar 2010
Location: Plano, Texas
Posts: 23
I am cleaning up the block right now and when I'm done I will have it sonic tested. I will put the results up here when I get it done in a few weeks or so.
__________________
1969 red 442 convertible w/ black stripes
1969 blue 442 convertible w/ white stripes
red&blue442 is offline   Reply With Quote
Old January 15th, 2011, 04:58 PM   #25
Registered User

ralsy's Avatar

Join Date: Jul 2010
Location: Sunshine Coast
Posts: 315
Good on ya Red & Blue 442. We can then finally solve this mystery. Looking fwd to the results. This seems to be an issue which has been raised numerous times before with out a real satisfactory answer. It also seems that there are lots of people who would like to improve their 400ci engines performance but not necessarily change the original look of their engine (keeping it the stock look). I think most people understand that we will probably never have the performance gains that you would get with a 455ci. All we want is to get the best performance we can. Me, personally, whose 69 442 is mostly numbers matching (except for paint) would like to keep the original look but up the performance.
I think 400Hp+ is achievable without over boring.
Such as-
Headers
Jp 20-22 cam and accessories (lifters, R rockers, etc)
W30 carb or equivalent
Electronic ignition
Performance intake (paint it same colour as engine)
ralsy is offline   Reply With Quote
Old January 15th, 2011, 05:15 PM   #26
Registered User

red&blue442's Avatar

Join Date: Mar 2010
Location: Plano, Texas
Posts: 23
Yeah I wouldn't bore it out if it's numbers matching cause once you do there's no going back. Both my 69s are numbers matching but I have am extra g block out of a junker so I figured it'd be cool to build for all out power and put in one of the cars for fun, and then I'd still have to stock engine to go back to numbers matching if I wanted.
__________________
1969 red 442 convertible w/ black stripes
1969 blue 442 convertible w/ white stripes
red&blue442 is offline   Reply With Quote
Old January 16th, 2011, 09:02 PM   #27
Just the facts...

BILL DEMMER's Avatar

Join Date: May 2008
Location: THE GREAT WIDE-OPEN
Posts: 1,146
if memory serves...
i think it was Dave H. over at ROP that was saying they were the same internal sand castings.


bill
__________________
'67 CUTLASS 4-DR. W/425 & S.P. THM400 (NAMED "ERNIE")
'83 H/O #1339(STILL IN PIECES)
'85 PONTIAC FIERO SE V-6 4-SPD. BOUGHT NEW
'92 CHEBBY ASTRO
'97 GEO METRO LSi 41.42 MPG
BILL DEMMER is offline   Reply With Quote
Old November 26th, 2011, 06:19 PM   #28
L69
Drop Top Stick 442

L69's Avatar

Join Date: Oct 2011
Location: Connecticut
Posts: 795
Find a 455 block. They are reasonably priced and I would not bore a 3.87 to 4.125. That is a bit overkill. Thats .255 overbore. Find a 455 or buy a rare but much more desirable early 400/425 that is all I deal with and they have a much better rod to stroke ratio including oversquare. RPM's are easier to achieve, only drawback is the cost to build them, depending on the cba and or lifter size.
L69 is offline   Reply With Quote
Old November 27th, 2011, 01:12 PM   #29
Registered User

64Rocket's Avatar

Join Date: Sep 2006
Location: Union City Calif.94587
Posts: 1,692
Gene McKay
This a pretty old thread. I guess "Red&Blue" did not get the info on the sonic check. I'm thinking he never did the engine either.

Gene
__________________
64Rocket is offline   Reply With Quote
Old November 27th, 2011, 01:12 PM
ClassicOldsmobile
1957 Oldsmobile




Paid Advertisement



submit to reddit
Reply

Thread Tools Search this Thread
Search this Thread:

Advanced Search
Display Modes

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off
Trackbacks are Off
Pingbacks are Off
Refbacks are Off


Similar Threads
Thread Thread Starter Forum Replies Last Post
455 cid destributer removal greenslade Big Blocks 4 February 1st, 2010 02:52 PM
65 400 block for sale Oldsmaniac Parts For Sale 4 September 22nd, 2009 03:13 PM
330 250hp? 400 cid ? 5636Randy Small Blocks 0 March 25th, 2008 05:23 PM
1975 Cutlass supreme coupe 455-cid joyce Cars For Sale 3 February 25th, 2007 07:12 PM
1969 w30 400 CID intake manifold mdk442 Parts Wanted 1 December 3rd, 2006 07:01 PM


All times are GMT -7. The time now is 06:29 PM.


Advertising - Privacy Statement - Terms of Service - Jobs
All content Copyright © 2008 by Internet Brands, Inc.
